GIUNTI ROTANTI PER OLIO IDRAULICO E ARIA
| ARIA | OLIO Via Centrale |
OLIO Via Laterale |
||
| T MAX | °C | 90 | 90 |
90 |
| P MAX | bar | 12 | 100 |
70 |
| N MAX | min-1 | 3000 | 3000 |
3000 |
 |
| TIPO |
A BSP |
C
|
D | E | F | G | H | I | L2 | M | N | P | Q | T | U2 | Z | |
| GD 06 2U/F | 1/4 | 6 | 35 | 13.5 | 22 | 65 | 12 | 5 | 150 | 85 | 39 | 65 | 39 | 25 | 107.5 | 13 |  |
| GD 10 2U/F | 3/8 | 9 | 45 | 17 | 28 | 75 | 12 | 8 | 177 | 95 | 46 | 80 | 45 | 30 | 124 | 13 | |
| GD 13 2U/F | 1/2 | 13 | 50 | 22 | 34 | 85 | 12 | 8 | 191 | 105 | 39.5 | 100 | 62 | 37 | 130 | 13 | |
| GD 18 2U/F | 3/4 | 18 | 60 | 30 | 50 | 100 | 16 | 10 | 218 | 130 | 43 | 115 | 75 | 43 | 142 | 18 | |
